AM Demodulation Specifics

The algorithm

Envelope = √real

+ imag

AM =

√real

+ imag

−Carr Amplitude

_______________

Carr Amplitude

_______________

where AM = modulation index

Carr Amplitude

_______________

= carrier amplitude averaged across the entire time record.

AM demodulation averages the carrier amplitude to derive the modulation index from the

envelope

Analog Demodulation Concepts

20 - 9
