100 6000 Series Oscilloscope User’s Guide
2 Front-Panel Controls
To set up the screen saver
The oscilloscope can be configured to turn on a display screen
saver when the oscilloscope has been idle for a specified length
of time.
1 Press Utility&Options&Preferences&Screen Saver to display the
screen saver menu.
2 Press the Saver softkey to select the screen saver type.
The screen saver can be set to Off, to display any of the
images shown in the list, or can display a user-defined text
string.
If User is selected, press the Spell softkey to select the first
character of the text string. Use the Entry knob to choose a
character. Then press the Enter softkey to advance to the next
character and repeat the process. The resultant string is
displayed in the "Text =" line above the softkeys.
NOTE
The Screen Saver is disabled on 6000L models.
Screen saver
Screen saver
time delay
Return to
previous menu
Preview
Select
characters
Advance to next
character
List of characters displayed
when Entry knob is turned
User-defined
text string
