Reference 8
6000 Series Oscilloscope User’s Guide 339
Examples of Binary Files
Single Acquisition Multiple Analog Channels
The following picture shows a binary file of a single acquisition
with multiple analog channels.
File Header
12 bytes
Number of Waveforms = N
Number of Waveform Buffers = 1
Buffer Type = 1 (floating point)
Bytes per Point = 4
Waveform Header 1
140 bytes
Waveform Data
Header 1
12 bytes
Voltage Data 1
buffer size
Waveform Header 2
140 bytes
Waveform Data
Header 2
12 bytes
Voltage Data 2
buffer size
Waveform Header N
140 bytes
Waveform Data
Header N
12 bytes
Voltage Data N
buffer size
Number of Waveform Buffers = 1
Buffer Type = 1 (floating point)
Bytes per Point = 4
Number of Waveform Buffers = 1
Buffer Type = 1 (floating point)
Bytes per Point = 4
