318 6000 Series Oscilloscope User’s Guide
7 Saving and Printing Data
To use the file explorer
The File Explorer menu lets you load or delete files from a USB
mass storage device.
1 Connect a USB mass storage device to the USB port on the
front or the rear of the oscilloscope. A small colored circle
icon will be displayed as the USB device is read.
2 Press Utility&File Explorer.
3 Press the far left softkey and turn the Entry knob to select
the USB mass storage device, and a directory and file on the
USB mass storage device.
You can create directories on a USB mass storage device
using your PC or other instrument. You can navigate to any
directory that you have made using the Entry knob and the
far left softkey.
NOTE
Do not connect USB “hub” devices or USB devices that identify
themselves as hardware type “CD” because these devices are
not compatible with the 6000 Series oscilloscopes.
Navigate
using Entry
knob, select
using this key
Load selected
file
Return to
previous menu
Delete selected
file
To Next Page
