346 6000 Series Oscilloscope User’s Guide
9 Characteristics and Specifications
6000A Series Oscilloscope Characteristics
All characteristics are the typical performance values and are
not warranted. Characteristics are valid after a 30-minute
warm-up period and within ±10°C of last “User Cal”
temperature.
Table 20 Characteristics
Acquisition: oscilloscope channels
Sample rate MSO/DSO601xA/603xA: 2 GSa/sec each channel
MSO/DSO605xA/610xA: 4 GSa/sec half channel*, 2 GSa/sec each channel
Standard memory depth With logic channels turned off,
2 Mpts half channel*, 1 Mpts each channel
With logic channels turned on,
1.25 Mpts half channel*, 625 kpts each channel
Optional memory depth With logic channels turned off,
Option 2ML or 2MH – 2 Mpts half channel*, 1 Mpts each channel
Option 8ML or 8MH – 8 Mpts half channel*, 4 Mpts each channel
With logic channels turned on,
Option 2ML or 2MH – 1.25 Mpts half channel*, 625 kpts each channel
Option 8ML or 8MH – 5 Mpts half channel*, 2.5 Mpts each channel
Vertical resolution 8 bits
Peak detection MSO/DSO601xA: 1-ns peak detect
MSO/DSO603xA: 500-ps peak detect
MSO/DSO605xA/610xA: 250-ps peak detect
Averaging Selectable from 2, 4, 8, 16, 32, 64 … to 65536
High resolution mode Average mode with #avg = 1
12 bits of resolution when ≥10 µs/div, at 4 GSa/s or ≥20 µs/div, at 2 GSa/s
Filter Sinx/x interpolation (single shot BW = sample rate/4 or bandwidth of oscilloscope,
whichever is less) with vectors on and in real-time mode
* Half channel is when only one of channel pair 1 or 2 is turned on, or only one of channel pair 3 or 4 is turned on.
