180 6000 Series Oscilloscope User’s Guide
4 Triggering the Oscilloscope
Assign
channels
# data bits
in string
Data bit
select
Set all
data bits
to value
Trigger level
or threshold
Currently selected Clock,
Framing, or Data channel
SPI trigger
Return to
previous menu
Data bit
value
Data string
values
Graphic showing
current state of the
SPI trigger setup
