Agilent Technologies MSO6012A User Manual

Making Measurements 5
6000 Series Oscilloscope User’s Guide 201
Figure 21 Example of centering a signal on the display
Figure 22 Signal centered on the display
4 Press the Cursors key.
5 Set the Y2 cursor to the top of the signal, and set Y1 to
the bottom of the signal.
A
B
D
C
Signal must
be centered in
“X”
