Displaying Data 6
6000 Series Oscilloscope User’s Guide 285
g If the decode line does not appear on the display, press the
up-arrow softkey to return to the previous menu, then
press the Decode softkey.
5 If the oscilloscope is stopped, press the Run/Stop key to
acquire and decode data.
You can use the Delayed horizontal sweep mode for easier
navigation of the decoded data.
NOTE
Changing the Trigger settings in the Serial Decode setup also changes
them in the Trigger setup.
NOTE
If the setup does not produce a stable trigger, the LIN signal may be slow
enough that the oscilloscope is AutoTriggering. Press the Mode/Coupling
key, then press the Mode softkey to set the trigger mode from Auto to
Normal.
