Characteristics and Specifications 9
6000 Series Oscilloscope User’s Guide 349
Horizontal
Range MSO/DSO601xA: 5 nsec/div to 50 sec/div
MSO/DSO603xA: 2 nsec/div to 50 sec/div
MSO/DSO605xA: 1 nsec/div to 50 sec/div
MSO/DSO610xA: 500 psec/div to 50 sec/div
Resolution 2.5 psec
Timebase accuracy 15 ppm (±0.0015%)
Vernier 1-2-5 increments when off, ~25 minor increments between major settings when on
Delay range Pre-trigger (negative delay):
Greater of 1 screen width or 1 ms (with 8 Mpts memory option)
Greater of 1 screen width or 250 µs (with 2 Mpts memory option)
Greater of 1 screen width or 125 µs (with standard memory)
Post-trigger (positive delay): 1 s - 500 seconds
Analog delta-t accuracy Same channel: ±0.0015% reading ±0.1% screen width ±20 ps
Channel-to-channel: ±0.0015% reading ±0.1% screen width ±40 ps
Same channel example (MSO/DSO605xA):
For signal with pulse width of 10 µs, oscilloscope set to 5 µs/div (50 µs screen width),
delta-t accuracy = ±{0.0015% (10 µs) + 0.1% (50 µs) + 20 ps} = 50.17 ns
Logic delta-t accuracy Same channel: ±0.005% reading ±0.1% screen width ±(1 logic sample period, 1 ns)
Channel-to-channel: ±0.005% reading ±0.1% screen width ±(1 logic sample period)
±chan-to-chan skew
Same channel example:
For signal with pulse width of 10 µs, oscilloscope set to 5 µs/div (50 µs screen width),
delta-t accuracy = ±{0.005% (10 µs) + 0.1% (50 µs) + 1 ns} = 51.5 ns
Modes Main, delayed, roll, XY
XY Bandwidth: Max bandwidth
Phase error @ 1 MHz: <0.5 degrees
Z Blanking: 1.4 V blanks trace (use external trigger on MSO/DSO6xx2A,
channel 4 on MSO/DSO6xx4A)
Reference positions Left, center, right
Trigger system
Sources MSO6xx2A: Ch 1, 2, line, ext, D15 - D0
DSO6xx2A: Ch 1, 2, line, ext
MSO6xx4A: Ch 1, 2, 3, 4, line, ext, D15 - D0
DSO6xx4A: Ch 1, 2, 3, 4, line, ext
Modes Auto, Normal (triggered), single
Holdoff time ~60 ns to 10 seconds
Trigger jitter 15 ps rms
