Show, Clear, Debug Commands
Page 868 7210 SAS M Services Guide
1/1/1:200 200 1 none 1none Up Up
1/1/3:100.200 200 1 none 1none Up Up
1/1/1:300 300 1 none 1none Up Up
-------------------------------------------------------------------------------
Number of SAPs : 5
-------------------------------------------------------------------------------
*A:ALU_SIM2>config>service>vpls#
sdp
Note : SDP commands are not supported by 7210 SAS-M devices configured in uplink mode.
Syntax sdp [sdp-id | far-end ip-addr] [detail | keep-alive-history]
Context show>service>id
Description This command displays information for the SDPs associated with the service.
If no optional parameters are specified, a summary of all associated SDPs is displayed.
Parameters sdp-id — Displays only information for the specified SDP ID. An SDP is a logical mechanism that
ties a far-end 7210 SAS M to a particular service without having to specifically define far end
SAPs. Each SDP represents a method to reach a 7210 SAS M router.
Default All SDPs.
Values 1 — 17407
far-end ip-addr — Displays only SDPs matching with the specified system IP address of the far-end
destination 7210 SAS M router for the Service Distribution Point (SDP) that is the termination
point for a service.
Default SDPs with any far-end IP address.
detail — Displays detailed SDP information.
Output Show Service SDP — The following table describes show service-id SDP output fields.
Label Description
Sdp Id
The SDP identifier.
Type
Indicates whether the SDP is a spoke.
VC Type
Displays the VC type, ether or vlan.
VC Tag
Displays the explicit dot1Q value used when encapsulating to the SDP
far end.
I. Lbl
The VC label used by the far-end device to send packets to this device
in this service by the SDP.
Admin Path MTU
The operating path MTU of the SDP is equal to the admin path MTU
(when one is set) or the dynamically computed tunnel MTU, when no
admin path MTU is set (the default case.)
