VPLS Show Commands
7210 SAS M Services Guide Page 923
MC Standby : no
-------------------------------------------------------------------------------
Number of groups: 1
===============================================================================
*A:7210-SAS>show>service>id>i
proxy-db
Syntax proxy-db [detail]
proxy-db group grp-address
Context show>service>id>igmp-snooping
Description This command displays information on the IGMP snooping proxy reporting database for the VPLS
service.
Parameters group grp-ip-address — Displays the IGMP snooping proxy reporting database for a specific
multicast group address.
Output Show Output — The following table describes the show output fields:
Sample Output
*A:MTU-7210# show service id 100 igmp-snooping proxy-db
===============================================================================
IGMP Snooping Proxy-reporting DB for service 100
===============================================================================
Group Address Up Time
-------------------------------------------------------------------------------
227.7.7.7 0d 00:05:30
227.7.7.8 0d 00:05:30
228.8.8.8 0d 00:03:42
-------------------------------------------------------------------------------
Number of groups: 3
Label Description
Group Address
The IP multicast group address for which this entry contains infor-
mation.
Mode
Specifies the type of membership report(s) received on the interface
for the group. In the include mode, reception of packets sent to the
specified multicast address is requested only from those IP source
addresses listed in the source-list parameter of the IGMP member-
ship report.
In the “exclude” mode, reception of packets sent to the given multi-
cast address is requested from all IP source addresses except those
listed in the source-list parameter.
Up Time
The total operational time in seconds.
Number of groups
Number of IGMP groups.
