Virtual Private LAN Services
7750 SR OS Services Guide Page 709
The QinQ and TopQ SAP PBit marking follows the default behavior defined in the above tables when
qinq-mark-top-only is not specified.
The dot1p dot1p-value command must be configured without the qinq-mark-top-only parameter to
remove the TopQ PBits only marking restriction.
Egress SAP
Type
Ingress Packet Preserved
Dot1P State
Marked (or Remarked) PBits
Null No preserved Dot1P bits None
Null Preserved Dot1P bits Preserved tag PBits remarked using
dot1p-value
Dot1Q No preserved Dot1P bits New PBits marked using dot1p-value
Dot1Q Preserved Dot1P bits Preserved tag PBits remarked using
dot1p-value
TopQ No preserved Dot1P bits TopQ PBits marked using dot1p-value
TopQ Preserved Dot1P bits (used as TopQ
and BottomQ PBits)
TopQ PBits marked using dot1p-value,
BottomQ PBits preserved
QinQ No preserved Dot1P bits TopQ PBits and BottomQ PBits marked
using dot1p-value
QinQ Preserved Dot1P bits (used as TopQ
and BottomQ PBits)
TopQ PBits and BottomQ PBits marked
using dot1p-value
Egress SAP
Type
Ingress Packet Preserved
Dot1P State
Marked (or Remarked) PBits
Null No preserved Dot1P bits None
Null Preserved Dot1P bits Preserved tag PBits remarked using
dot1p-value
Dot1Q No preserved Dot1P bits New PBits marked using dot1p-value
Dot1Q Preserved Dot1P bits Preserved tag PBits remarked using
dot1p-value
TopQ No preserved Dot1P bits TopQ PBits marked using dot1p-value
TopQ Preserved Dot1P bits (used as TopQ
and BottomQ PBits)
TopQ PBits marked using dot1p-value,
BottomQ PBits preserved
QinQ No preserved Dot1P bits TopQ PBits marked using dot1p-value,
BottomQ PBits marked with zero
QinQ Preserved Dot1P bits (used as TopQ
and BottomQ PBits)
TopQ PBits marked using dot1p-value,
BottomQ PBits marked using preserved
value
