1756-6.5.3 - December 1999
D-2 Setting Paths for Downloads in RSLogix5000, Version 2.10
2. Select the Communications tab and enter the following configuration to
download through the 1756-CNB module at node 1:
-OR-
Enter the following configuration to download through the 1756-CNB
module at node 6:
3. From the Communications menu, select Download.
The Download prompt will appear containing the path you specified.
4. Click on the Download button to download the program to the
Logix5550 controller.
In this field Select
Driver
AB_KTC-1
(1)
(1)
This is the default name for the KTCx driver configured in chapter 2 using
RSLinx.
Path 2, 1, 1, 0
In this field Select
Driver
AB_KTC-1
(1)
(1)
This is the default name for the KTCx driver configured in chapter 2 using
RSLinx.
Path 2, 6, 1, 0
