1756-6.5.3 - December 1999
Adding an I/O Chassis to an Existing ControlNet Network 11-9
11.Click on Finish to accept the configuration.
The I/O Configuration tree should now look similar to the one shown
below.
Edit the Controller Tags
1. Double-click on the Controller Tags folder in the project window.
2. Note that new tags have been added for the remote CNB module and the
remote analog I/O module.
Tags for new remote
1756-CNB and remote
analog I/O created by the
system.
