1756-6.5.3 - December 1999
4-12 Logix5550 to Logix5550 Controller: Scheduled Communication
3. Enter the following parameters:
4. Click on the Finish button to accept the configuration.
The I/O Configuration tree should look similar to the one shown below.
Create the Consumer Tags
1. Double-click on the Controller Tags folder in the project window.
Name Producer
Slot 0
See Appendix B for additional
information on consumer tags.
