Allen-Bradley ControlLogix User Manual

1756-6.5.3 - December 1999
P-3
System Components
We used the following main components to set up the example applications:
Quantity Product Name Catalog Number Series Firmware
Revision
Hardware
3 ControlLogix chassis 1756-A4, (or -A7, -A13, -A13,
-A17)
A-
3 ControlLogix power supply 1756-PA72, -PB72 A -
3 ControlLogix ControlNet Interface Module 1756-CNB, (or -CNBR)
B
(1)
2.10
2 Logix5550 controller 1756-L1 A 4.41
2 PLC-5 processor, ControlNet version 1785 -L40C15 D C
1 ControlNet Communication Interface Card 1784-KTCX15 - -
1 Analog Output Module 1756-OF6VI A 1.5
1 Digital Input Module 1756-IB16 A 2.4
1 Digital Output Module 1756-0B16I A 1.5
1 personal computer that supports RSLogix software any appropriate model running
Windows 95/98 or NT 4.0
--
associated wiring and cabling as needed
Software Version
1 RSLinx 9355-WAB, -WABOEM, -WABC
(Windows 95/98, NT 4.0)
-2.10
1 RSLogix5 programming software 9324-RL5300ENE
(Windows 95/98, NT 4.0)
-3.21
1 RSLogix5000 programming software 9324-RLD300ENE
(Windows 95/98, NT 4.0)
-
2.25
(2)
1 RSNetWorx for ControlNet software 9357-CNETL3
(Windows 95/98, NT 4.0)
-1.80
(1)
To receive a free firmware upgrade from series A to series B, contact Rockwell Technical Support. See page P-5.
(2)
Version 2.10 may also be used. See Appendix D.

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
