Logix5550 to Logix5550 Controller: Unscheduled Messaging 3-3
Create the Controller Tags for the Write Message Program
1. Double-click on the Controller Tags folder in the project window.
The Controller Tags window will appear.
2. Select the Edit Tags tab and create the following tags:
Tag Name Alias For Base Tag Type Style
L1_to_L1 MESSAGE
Source_data_buffer T1.ACC T1.ACC DINT
Decimal
T1 TIMER
