1756-6.5.3 - December 1999
Logix5550 to Logix5550 Controller: Scheduled Communication 4-3
Create the Producer Tags
1. Double-click on the Controller Tags folder in the project window.
The Controller Tags window will appear.
2. Select the Edit Tags tab and create the following tags:
Tag Type Style
produced_data DINT
Decimal
T1 TIMER
See Appendix B for additional
information on producer tags.
