Allen-Bradley ControlLogix - Create the Controller Tags for the Logix5550 Controller

1756-6.5.3 - December 1999
7-8 PLC-5C to Logix5550 Controller: Unscheduled Messaging
Create the Controller Tags for the Logix5550 Controller
1. Double-click on the Controller Tags folder in the project window.
The Controller Tags window will appear.
2. Select the Edit Tags tab and create the following tag:
Tag Name Type Style
PLC5_Data INT
Decimal
