Where to Find More
Information
Refer to the following publications as needed for additional help when
setting up and using your ControlNet network:
Rockwell Automation Support
Rockwell Automation offers support services worldwide, with over 75
sales/support offices, 512 authorized distributors, and 260 authorized
systems integrators located throughout the United States alone, plus
Rockwell Automation representatives in every major country in the world.
Local Product Support
Contact your local Rockwell Automation representative for:
• sales and order support
• product technical training
• warranty support
• support service agreements
0RUH
For information about See this publication Publication number
network cabling and wiring ControlNet Cable Planning and Installation Guide 1786-6.2.1
the ControlLogix ControlNet Interface Module ControlLogix ControlNet Bridge Installation Instructions 1756-5.71
the ControlLogix Chassis ControlLogix Chassis Installation instructions 1756-5.2
ControlLogix power supplies ControlLogix Power Supplies Installation Instructions 1756-5.1
Logix5550 programmable controllers Logix5550 Controller User Manual 1756-6.5.12
PLC-5 programmable controllers Enhanced PLC-5 Programmable Controller Quick Start 1785-10.4
ControlNet PLC-5 Programmable Controller Quick Start 1785-10.7
ControlNet PLC-5 Programmable Controller User Manual 1785-6.5.22
ControlLogix Analog I/O modules ControlLogix Analog I/O Users Manual 1756-6.5.9
ControlLogix Digital I/O modules ControlLogix Digital I/O Users Manual 1756-6.5.8
PC communication interface cards 1784-KTX15 Communication Interface Card User Manual 1784-6.5.22
RSLogix5 programming software Getting Results with RSLogix5 9399-RL53GR
RSLogix5000 programming software Getting Results with RSLogix5000 9399-RLD300GR
RSNetWorx for ControlNet software Getting Results with RSLogix with RSNetWorx for ControlNet 9399-RWCNTGR
RSLinx Lite software RSLinx Lite User’s Guide 9399-WAB32LUG
current Allen-Bradley documentation,
including ordering instructions
Allen-Bradley Publication Index SD499
terms and definitions Allen-Bradley Industrial Automation Glossary AG-7.1
Many of these manuals are available online from the Automation
Bookstore, http://www.theautomationbookstore.com
.
For more information on Rockwell Software products, visit the Rockwell
Software internet site, http://www.software.rockwell.com
.

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
