Table 4.5 User-adjustable Parameters for Arcuate Incisions
Feature Default
a
a.Parameters do not have default values; the user must select each parameter.
Range Increment Step Size Units
Incision Type N/A Single, Symmetric, Asymmetric N/A N/A N/A
Centering Method N/A
Pupil, Limbus, Scanned Capsule,
Custom
N/A N/A N/A
Penetration Type Anterior Anterior or Intrastromal N/A N/A N/A
Depth Units Percentage Percentage or Absolute N/A N/A N/A
Axis
b
b.Independently adjustable parameters for asymmetric incisions.
N/A 0-360 1 5 °
Optical Zone
b
N/A 2-11 0.1 0.1 mm
Arc Length
b
N/A 10-120 1 5 °
Uncut Length
Anterior
c
Posterior
c.Not applicable for anterior penetrating.
20%, 100 µm
20%, 100 µm
20-50% (100-250 µm)
20-50% (100-250 µm)
1% (1 µm)
1% (1 µm)
2% (10 µm)
2% (10 µm)
% (µm)
Side Cut Angle
90 30-150 1 5 °
Line Density
b
Anterior
Central
10
4
1-10
1-10
1
1
1
1
N/A
N/A
Anterior Line Distance
d
d.Note that the central line distance is not user‐adjustable. (It is the difference between the sum of anterior
and posterior line distances.)
30% (150 µm) 0-80% (0-400 µm) 1% (1 µm) 5% (25 µm) % (µm)
Spot Spacing
Horizontal
Vertical
5
10
3-50
5-50
1
1
5
5
µm
µm
Pulse Energy 5 3-10 0.1 0.5 µJ
