AInstruction Coding
A – 3
Type 10: Conditional Jump (Immediate Address)
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 1 1 S ADDR COND
Type 11: Do Until
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 1 0 1 ADDR TERM
Type 12: Shift with Data Memory Read / Write
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 1 0 0 1 G D SF Xop DREG I M
Type 13: Shift with Program Memory Read / Write
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 1 0 0 0 1 D SF Xop DREG I M
Type 14: Shift with Internal Data Register Move
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 1 0 0 0 0 0 SF Xop Dest Source
DREG DREG
Type 15: Shift Immediate
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 1 1 1 1 0 SF Xop exponent
Type 16: Conditional Shift
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 1 1 1 0 0 SF Xop 0 0 0 0 COND
