AInstruction Coding
A – 5
Type 22: Reserved
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 COND
Type 23: DIVQ
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 0 1 1 1 0 0 0 1 0 Xop 0 0 0 0 0 0 0 0
Type 24: DIVS
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 0 1 1 0 0 0 0 Yop Xop 0 0 0 0 0 0 0 0
Type 25: Saturate MR
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 0 1 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Type 26: Stack Control
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 PP LP CP SPP
Type 27: Call or Jump on Flag In
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 0 0 1 1 Address Addr FIC S
12 LSBs 2 MSBs
Type 28: Modify Flag Out
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 0 0 1 0 0 0 0 0 FO FO FO FO COND
FL2 FL1 FL0 FLAG_OUT
