1-2 3GPP Signal Analysis Overview General Information
1-2 PN: 10580-00234 Rev. T 3GPP MG
LTE
LTE signal analysis is described in Chapter 5, “LTE Signal Analyzer”.
• Option 541: LTE/LTE-A RF Measurements
• Option 542: LTE/LTE-A Modulation Measurements
• Option 546: LTE/LTE-A OTA Measurements (requires Options 31 and 542 for full
functionality)
• Option 883: LTE/LTE-A FDD/TDD Measurements
TD-LTE
TD-LTE signal analysis is described in Chapter 6, “TD-LTE Signal Analyzer”.
• Option 551: TD-LTE/LTE-A RF Measurements
• Option 552: TD-LTE/LTE-A Modulation Measurements
• Option 556: TD-LTE/LTE-A OTA Measurements (requires Options 31 and 552 for full
functionality)
• Option 883: LTE/LTE-A FDD/TDD Measurements
LTE and TD-LTE coverage mapping is described in Chapter 7, “LTE and TD-LTE Coverage
Mapping”.
EMF measurements in the LTE and TD-LTE Signal Analyzer modes are described in
Chapter 8, “EMF (Option 444)”.
1-3 Selecting a Measurement Mode
Select a measurement mode by pressing Shift and then the Mode (9) button to open the Mode
Selector dialog box. Highlight the desired measurement mode using the Up or Down arrow
keys and press Enter.
Figure 1-1. Mode Selector Dialog Box
