W-CDMA/HSPA+ Signal Analyzer 3-8 W-CDMA/HSPA+ Menus
3GPP MG PN: 10580-00234 Rev. T 3-25
Figure 3-15. W-CDMA/HSPA+ Menu Layout (2 of 2)
Demodulator
CDP
CDP
Table
HSDPA
Codogram
Modulation
Summary
Back
CDP
Zoom
32 64 128
Zoom Start
0
Control Channels
Rel Abs Delta
Back
HSDPA
IQ Persistence
1
Back
Next Active
Code
Left
Total Time
240 s
Single Sweep Time
5 s
Codogram
Zoom
32 64 128
Zoom Start
0
Total Time
240 s
Back
Single Sweep Time
5 s
Pass/Fail Mode
ScriptMaster
Select
Pass/Fail
Test
Back
ScriptMaster
Change File Header
Test_Seq_1
Start Test
Exit
Reset
Skip
G
OTA Setup
Scrambling Code
Manual Auto
Manual Code
1 2 3 4 5 6
On
Off
Code Lock
On Off
Display Unit
CPICH EC/Io
Sort By
Code Power
Code Lock Reset
Back
H
I
Over-The-Air
Scrambling Code
Multipath
Back
Multipath
Scrambling Code
Auto Manual
Manual Scrambling
Code
351
Vert Display
RSCP Rel Pwr
Horiz Display
Chips uSec
Distance
m ft
Back
EMF
EMF
Measurement
On Off
EMF Units
V/m
Number of
Measurements
5
Measurement Time
6 min
Auto Logging
On Off
Limits
6.00 V/m
Measurement
Parameters
Back
Option 444
Refer to Chapter 8
Control Channels
Rel Abs Delta
Next Active
Code
Right
Selected Code #
2
