W-CDMA/HSPA+ Signal Analyzer 3-11 Setup Menu
3GPP MG PN: 10580-00234 Rev. T 3-29
Setup 2/2 Menu
Key Sequence: Setup > More
Threshold: Sets the measurement threshold to be set either automatically
by the instrument or manually by the user.
Manual Threshold: Change the measurement threshold manually by
entering a desired value and pressing Enter.
Max Amp Pwr: Sets the maximum transmit power of the base station.
CPICH Pwr: Sets the power of the CPICH.
Freq Err Avg: Turns on averaging for the frequency error measurement.
Freq Err Avg Cnt: Sets the number of measurements to use in the
frequency error averaging calculations. The number can be set from 2 to 15.
Sync Type: Selects between CPICH or No CPICH for synchronization.
Back: Returns to the “Setup 1/2 Menu” on page 3-28.
Figure 3-19. W-CDMA/HSPA+ Setup Menu (2/2)
Setup 2/2
Threshold
Auto Manual
Manual Threshold
-18.5 dB
Max Amp Pwr
10.0 dBm
CPICH Pwr
10.0 dBm
Freq Err Avg
Off On
Freq Err Avg Cnt
2
Sync Type
CPICH No CPICH
Back
To Next Page
