Anritsu MT8212E - Page 283

TD-LTE Signal Analyzer 6-12 Measurements Menu
3GPP MG PN: 10580-00234 Rev. T 6-35
Channel Spectrum Menu
Key Sequence: Measurements > RF > Channel Spectrum
Power vs. Time Menu
Key Sequence: Measurements > RF > Power vs. Time
Span: Opens the Span list to select a span of Auto, 1.4 MHz, 3 MHz,
5 MHz, 10 MHz, 15 MHz, 20 MHz, or 30 MHz.
Back: Returns to the “RF Menu” on page 6-34.
Figure 6-28. TD-LTE Channel Spectrum Menu
View: Press to select either Frame or Sub-Frame
Sub-Frame Number: If Sub-Frame is selected, press to enter the desired
sub-frame to view.
Back: Returns to the “RF Menu” on page 6-34.
Figure 6-29. TD-LTE Power vs. Time Menu
Back
Channel Spectrum
Span
10 MHz
View
Frame Sub-Frame
Sub-Frame Number
0
Power vs. Time
Back
