6-12 Measurements Menu TD-LTE Signal Analyzer
6-36 PN: 10580-00234 Rev. T 3GPP MG
Spectral Emission Menu
Key Sequence: Measurements > RF > Spectral Emission
Category A B (Opt. 1): Select the desired category based on the
information on page 6-34.
Select Mask (Auto): Displays a list of standard and custom masks for use
in SEM measurements. Select “Auto Select” if the desired mask is
unknown.
Summary Table: Displays the Spectral Emission measurement data in
table form.
Back: Returns to the “RF Menu” on page 6-34.
Figure 6-30. TD-LTE Spectral Emission Menu
Category
A B (Opt. 1)
Summary Table
Off On
Spectral Emission
Back
Select Mask
(Auto)
