TD-LTE Signal Analyzer 6-12 Measurements Menu
3GPP MG PN: 10580-00234 Rev. T 6-47
Pass/Fail Test Menu
Key Sequence: Measurements > Pass/Fail Test > Select Pass/Fail Test
Select Pass/Fail Test: Press this submenu key to open the Select Pass/Fail
Test list box and select a test type. Choose from:
PASS_FAIL_RF
PASS_FAIL_MOD
PASS_FAIL_CONTROL
PASS_FAIL_ALL
Highlight the desired test with the arrow keys or rotary knob and press
Enter to start the test or press Esc to cancel your choice.
Note: The current list of pass/fail tests is a default list. Master Software Tools
(MST) includes features to create additional pass/fail tests.
Reset: Press this submenu key to restart the measurement or to begin a
new pass/fail test measurement.
Back: Press this submenu key to return to the “Measurements Menu” on
page 6-33.
Figure 6-41. TD-LTE Pass Fail Mode Menu
Back
Select
Pass/Fail
Test
Reset
Pass/Fail Test
