2-2 Cable and Antenna Measurement Setup Cable and Antenna Analyzer
2-2 PN: 10580-00241 Rev. B Cable & Antenna Analyzer MG
Frequency
(for VSWR, Return Loss, Cable Loss, Smith Chart, 1-Port Phase measurements)
Setting up the Measurement Frequency using Start and Stop Frequencies
1. Press the Freq/Dist main menu key.
2. Press the Start Freq submenu key and use the keypad to enter the start frequency.
When entering a frequency using the keypad, the soft key labels change to GHz, MHz,
kHz, and Hz. Press the appropriate unit key to complete the entry.
3. Press Stop Freq and use the keypad to enter the stop frequency. Press the appropriate
unit key to complete the entry.
Setting up the Measurement Frequency by Selecting a Signal Standard
1. Press the Freq/Dist main menu key.
2. Press the Signal Standard submenu key.
3. Select uplink, downlink, or uplink plus downlink.
4. Press the Select Standard key.
5. Use the rotary knob or the Up/Down arrow keys and scroll to the appropriate signal
standard and press Enter to select.
Frequency/Distance
(Distance-To-Fault Return Loss, Distance-To-Fault VSWR)
1. Press the Freq/Dist main menu key.
2. Press the Start Dist submenu key and use the keypad to enter the start distance.When
entering a distance using the keypad, the key label changes to m or ft. Press the unit
key or Enter to complete the entry.
3. Press Stop Dist and use the keypad to enter the stop distance. Press the unit key or
Enter to complete the entry.
4. To set the frequency, press DTF Aid. For more details about DTF Aid, refer to
“DTF Setup” on page 2-19.
Refer to “Freq Menu” on page 2-27 for additional information.
Note
The Signal Standard menu can be customized. If a particular standard is missing,
Master Software Tools (MST) can be used to edit the signal standard list. Please
see the MST manual for more details.
