Cable and Antenna Analyzer 2-9 Freq Menu
Cable & Antenna Analyzer MG PN: 10580-00241 Rev. B 2-27
2-9 Freq Menu
The Freq/Dist main menu key opens the Freq menu, or the Freq/Dist menu, depending upon
the type of measurement selected with the “Measurement Menu” on page 2-33.
Pressing the Freq/Dist main menu key after selection of DTF Return Loss or DTF VSWR on the
Measurement main menu will open the “Freq/Dist Menu” on page 2-29.
Key Sequence: Freq/Dist
Start Frequency: Press the Start Freq submenu key and enter the desired
frequency using the keypad, the arrow keys, or the rotary knob.
Stop Frequency: Press the Stop Freq submenu key and enter the desired
frequency using the keypad, the arrow keys, or the rotary knob.
Signal Standard: Opens the “Signal Standard Menu” on page 2-28.
Start Cal: Press this submenu key and follow the instruction on screen to
begin calibration. See Chapter 3 details.
Figure 2-21. Freq Menu
Freq
Start Freq
10.000 MHz
Stop Freq
4.000 GHz
Start Cal
Signal
Standard
To Next Page
