Cable & Antenna Analyzer MG PN: 10580-00241 Rev. B A-3
Nominal Side Lobe Windowing
This Distance To Fault graph has Return Loss (dB) on the vertical scale (y-axis) and distance
in feet on the horizontal scale (x-axis).
This view of Nominal Side Lobe Windowing shows less side lobe resolution than Rectangular
Windowing and more side lobe resolution than Low Side Lobe Windowing. This level of
windowing displays intermediate resolution.
Figure A-2. Nominal Side Lobe Windowing Example
–5
–10
–15
–20
–25
–30
–35
–40
–45
–50
5
10
15
20 25 30 35 40 45 50 55 60
