General Information 1-3 Recommended Test Equipment
MT8212E and MT8213E MM PN: 10580-00255 Rev. J 1-3
Table 1-2. Required Equipment for Cable and Antenna Analyzer Verification
Instrument Critical Specification
Recommended
Manufacturer/Model
Frequency Counter Frequency: 2 GHz Anritsu Model MF2412B
Open/Short Frequency: DC to 18 GHz Anritsu Model 22N50
Termination Frequency: DC to 18 GHz
Return Loss: 40 dB min.
Anritsu Model 28N50-2
RF Coaxial Cable Frequency: DC to 18 GHz
N(m) to N(f), 50 ohm
Anritsu Model 15NNF50-1.5C
6 dB Offset Termination Frequency: DC to 6.0 GHz Anritsu Model SC7424
20 dB Offset Termination Frequency: DC to 6.0 GHz Anritsu Model SC7423
Table 1-3. Required Equipment for Power Meter Functions
Instrument Critical Specification
Recommended
Manufacturer/Model
Synthesized Signal Source Frequency: 0.1 Hz to 20 GHz
Power Output: +13 dBm
Anritsu Model MG3692A or B with
options 2A, 4, 22, 15
a
a. Option 15 is required for MG3692A models to achieve power of +13 dBm. MG3692B models do not require Option 15.
Power Meter Power Range: –70 to +20 dBm Anritsu Dual Channel Model
ML2438A
Power Sensor Frequency: 10 MHz to 18 GHz
Power Range: –67 dB to +20 dB
Anritsu Model MA2442D
(Quantity 2)
Fixed Attenuator 10 dB Attenuation Aeroflex/Weinschel Model 44-10
Power Splitter Frequency: DC to 18 GHz Aeroflex/Weinschel Model 1870A
Adapter Frequency: DC to 20 GHz
N(m) to N(m), 50 ohm
Anritsu Model 34NN50A
Adapter Frequency: DC to 20 GHz
K(m) to N(f), 50 ohm
Anritsu Model 34RKNF50
RF Coaxial Cable Frequency: DC to 18 GHz
N(m) to N(m), 50 ohm
Anritsu Model 15NN50-1.5C
Frequency Reference Frequency: 10 MHz Symmetricom Model RubiSource
T&M
Table 1-4. Additional Test Equipment Required for Verifying Options (1 of 3)
Instrument Critical Specification Recommended Manufacturer/Model
Synthesizer (Opt. 31) Frequency: 0.1 Hz to 20 GHz
Power Output: +16 dBm
Anritsu Model MG3692A or MG3692B with
options 2A, 4, 15, and 22
a
