1-3 Recommended Test Equipment General Information
1-4 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
Vector Signal Generator
(Opt. 30, 32, 40, 41, 42, 43, 44,
45, 46, 47, 57, 60, 61, 62, 63,
64, 65, 66, 67, 78, 79, 541, 542,
551, 552)
Frequency: 100 kHz to 3 GHz Anritsu Model MG3700A with Options
MG3700A-002 and MG3700A-021
b. Waveform licenses for TD-SCDMA
(MX370001A), LTE (MX370108A) and
TD-LTE (MX370110A) are required and must
be purchased.
Power Meter Power Range: –70 to + 20 dBm Anritsu Model ML2438A
Power Sensor Frequency: 10 MHz to 18 GHz
Power Range: –60 to +20 dBm
Anritsu Model MA2482D with Option 1
(Quantity 2)
Frequency Reference Frequency: 10 MHz Symmetricom Model RubiSource T&M
Programmable Attenuator (Opt.
30, 32, 44, 45, 57, 64, 65, 79)
Frequency: DC to 2 GHz
Attenuation:100 dB
(1 dB and 10 dB steps)
Anritsu Model MN63A
Bit Error Rate Tester (Opt. 57) DVB ASI Input Anritsu MP8931A
Sonet Analyzer (Opt. 51, 52,
53)
Anritsu MP1570A with MP0121A and
MP0122A modules
Test Fixture (Opt. 52) Anritsu PN T3450
Digital Oscilloscope (Opt. 51,
52, 53)
LeCroy Model WaveRunner 62Xi with
ET-PMT Electrical Telecom Mask software
and TF-ET Telecom Adapter Set
Fixed Attenuator Frequency Range: DC to 18 GHz
Attenuation: 10 dB
Aeroflex/Weinschel Model 44-10
(Quantity 2)
RF Limiter (Opt. 30, 32, 79) Anritsu Model 1N50C
Power Splitter Frequency: DC to 18 GHz Aeroflex/Weinschel Model 1870A
RF Power Amplifier (Opt. 32,
44, 45, 57, 64, 65)
Frequency:100 to 1000 MHz
Gain: 35 dB min
Mini Circuits Model TIA-1000-1R8
(Quantity 2 BNC(m) to N(f) Adapters
required)
50 ohm Termination (Opt. 21) Frequency: DC to 18 GHz Anritsu Model 28N50-2
50 ohm Termination (Opt. 21) Frequency: DC to 18 GHz Anritsu Model 28NF50-2
High Power Load (Opt. 44, 45,
65)
DC to 18 GHz, 10W Aeroflex/Weinschel Model M1418
Coupler (Opt. 44, 45, 65) Frequency: 881.5 MHz
Coupling Factor: 30 dB
Midwest Microwave Model
CPW-5140-30-NNN-05 or
CPW-5141-30-NNN-05
Alternative: Anritsu part number 1091-307
[Two SMA(m) to N(f) adapters required.]
Circulator (Opt. 44, 45, 65) Frequency Range: 800 MHz to
1000 MHz
Isolation: 20 dB min
Meca Electronics, Inc. part number
CN-0.900
Alternative: Anritsu part number 1000-50
[Two SMA(m) to N(f) adapter and one
SMA(m) to SMA(m) Adapter required.]
RF Coaxial Cable Frequency: DC to 18 GHz
N(m) to N(m), 50 ohm
Anritsu Model 15NN50-1.5C(Quantity 3)
Table 1-4. Additional Test Equipment Required for Verifying Options (2 of 3)
Instrument Critical Specification Recommended Manufacturer/Model
