General Information 1-3 Recommended Test Equipment
MT8212E and MT8213E MM PN: 10580-00255 Rev. J 1-5
Coaxial Cable BNC(m) to BNC(m), 50 ohm Anritsu Model 2000-1627-R (Quantity 3)
Cable T1 Bantam Plug to
Bantam Plug (Opt. 51, 53)
Anritsu PN 806-16 (Quantity 2)
Cable 75 ohm BNC(m) to
BNC(m) (Opt. 52, 53)
Anritsu PN 3-806-169 (Quantity 2)
Cable RJ48 to dual Bantam
(Opt. 52)
Anritsu PN 806-117
GPS Antenna (Opt. 31) Anritsu 2000-1528-R
Adapter (Opt. 10) 40 ohm Load Anritsu Model T2904
Adapter (Opt. 10) 78 ohm Load Anritsu Model T3536
Adapter (Opt. 10) 105 ohm Load Anritsu Model T3377
Adapter (Opt. 30, 32, 57, 64,
79)
Frequency: 881.5 MHz
BNC(m) to N(f), 50 ohm
ADT-2615-NF-BNM-02 (Quantity 2)
Adapter (Opt. 44, 45, 65) Frequency: 881.5 MHz
SMA(m) to N(f), 50 ohm
Midwest Microwave Model
ADT-2582-NF-SMM-02 (Quantity 4)
[Required only if Anritsu Coupler and
Circulator are used.]
Adapter (Opt. 44, 45, 65) Frequency: 881.5 MHz
SMA(m) to SMA(m), 50 ohm
Midwest Microwave Model
ADT-2594-MM-SMA-02
[Required only if Anritsu Coupler and
Circulator are used.]
Adapter (Opt. 44, 45, 65) Frequency: DC to 20 GHz N(m)
to N(m), 50 ohm
Maury Microwave Model 8828B
Quantity: 2 each
[One each required only if Anritsu Coupler
and Circulator are used]
Adapter Frequency: DC to 20 GHz K(m)
to N(f), 50 ohm
Anritsu Model 34RKNF50
Adapter Frequency: DC to 20 GHz N(m)
to N(m), 50 ohm
Anritsu Model 34NN50A
Adapter (Opt. 51, 52, 53) BNC LeCroy PP090 75 ohm Telecom
Adapter (Opt. 52) LeCroy AP120 120 ohm Telecom
a. Option 15 is required for MG3692A models to achieve power of +13 dBm. MG3692B models do not require Option 15.
Table 1-4. Additional Test Equipment Required for Verifying Options (3 of 3)
Instrument Critical Specification Recommended Manufacturer/Model
