1-4 Replaceable Parts General Information
1-6 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
1-4 Replaceable Parts
Table 1-5. List of Replaceable Parts
Part Number Description
ND70944 MT8212E MB/VNA/SPA PCB Assy
a
(Instruments without options 57/79)
s/n < 1147089
ND74530 MT8212E MB/VNA/SPA PCB Assy
a
, with 20 MHz IF BW (Instruments without
options 57/79) s/n > 1147088 and s/n < 1230032
ND74540 MT8212E MB/VNA/SPA/BER PCB Assy
a
, with 20 MHz IF BW (Instruments with option
57/79) s/n < 1230032
ND75288 MT8212E MB/VNA/SPA PCB Assy
a
, with 20 MHz IF BW and locking keypad connector
(Instruments without options 57/79) s/n > 1230031
ND75290 MT8212E MB/VNA/SPA/BER PCB Assy
a
, with 20 MHz IF BW and locking keypad
connector (Instruments with option 57/79) s/n > 1230031
ND71743 MT8213E MB/VNA/SPA PCB Assy
a
(Instruments without options 57/79)
s/n < 1147089
ND74531 MT8213E MB/VNA/SPA PCB Assy
a
, with 20 MHz IF BW (Instruments without
options 57/79) s/n > 1147088 and s/n < 1231006
ND74541 MT8213E MB/VNA/SPA/BER PCB Assy
a
, with 20 MHz IF BW (Instruments with option
57/79) s/n < 1231006
ND75289 MT8213E MB/VNA/SPA PCB Assy
a
, with 20 MHz IF BW and locking keypad connector
(Instruments without options 57/79) s/n > 1231005
ND75291 MT8213E MB/VNA/SPA/BER PCB Assy
a
, with 20 MHz IF BW and locking keypad
connector (Instruments with option 57/79) s/n > 1231005
ND70945 T1 Assembly (Opion 51)
ND70946 E1 Assembly (Opion 52)
ND70947 T3/T1 Assembly (Opion 53)
3-67304-8 Model MT8212E ID Label
3-67304-10 Model MT8213E ID Label
ND70320 GPS Module (Opion 31)
3-15-147 LCD Display for units with Inverter PCB (unit s/n less than 1329107, plus unit s/n 1332170)
3-15-165 LCD Display for units with no Inverter PCB (unit s/n greater than 1329106, except unit s/n
1332170)
3-68567-3 Inverter PCB Assembly for LCD Backlight
2000-1654-R Soft Carrying Case
ND73191 Front Case with Gasket (excludes Model ID label, LCD, touch screen, encoder, and keypad
assemblies.)
ND74508 Front Case Kit (includes Keypad PCB, Rubber Keypad, Keypad Washers, Keypad Screws,
Encoder, Encoder Knob, Speaker Assembly with gaskets)
ND73199 Back Case (Excludes Tilt Bale)
ND73201 Battery Door
633-44 6600 mAH Li-Ion Battery Pack
633-75 7500 mAH Li-Ion Battery Pack
3-513-100 RF In Connector and RF Out Connector
40-187-R AC to DC Power Converter
3-410-103 Encoder (excluding knob)
