General Information 1-4 Replaceable Parts
MT8212E and MT8213E MM PN: 10580-00255 Rev. J 1-7
3-61360-2 Knob (excluding encoder)
ND73200 Tilt Bale Assy
3-72779 Fan Assembly
ND75294 Main Numeric Keypad PCB (Non-Locking connector)
ND75295 Main Numeric Keypad PCB (Locking connector)
3-72773 Rubber Keypad
3-72767 Keypad Washer
3-905-2744 Keypad Screw
ND73192 Speaker
3-72758 Vent 1 (Fan Vent, above battery door)
3-72759 Vent 2 (Intake Vent, top vent on keypad side)
3-72760 Vent 3 (Battery Vent, bottom vent on keypad side)
3-72771 Cable, Keypad to Main PCB, 15cm, non-locking connectors
3-74842-3 Cable, Keypad to Main PCB, 15cm, locking connectors
3-72770 Cable, Keypad to Inverter PCB, 6cm
3-71625-1 Cable, LCD to Keypad, units with LCD Display 3-15-165
3-72621-4 Cable, LCD to Main PCB, 7cm
3-803-110 Cable, Ribbon, 2x20, Main to SPA PCB
3-806-197 Cable, MMCX-MMCX, DSP to SPA PCB, units without BER
3-68764-3 Cable, MMCX-MMCX, 205mm, J1 to J6, units with BER
3-68764-4 Cable, MMCX-MMCX, 215mm, J2 to J3, units with BER
3-68764-5 Cable, MMCX-MMCX, 215mm, J4 to J4, units with BER
3-68764-6 Cable, MMCX-MMCX, 225mm, J61 to J5, units with BER
ND80480 Touch Screen with Protective Film
2000-1797-R Protective Film (Touch Screen not included)
a.When ordering the Main PCB Assembly, in order to ensureinstallation of correct options, all options that areinstalled on the
instrument must be declared on the order. The options are listed and shown in the System / Status display.
Table 1-5. List of Replaceable Parts
Part Number Description
