Measurement Commands
Measurements commands are all query which return a measurement result.
Note: These measurement commands apply to an individual CPS100 series power source.
For Master/Slave configuration measurement commands, refer also to Section
7.2.2, “Master / Slave Measurement Commands” on page 171.
Command Description
MEAS:VOLT? Returns the Voltage RMS value of the output in volts.
MEAS:VDC? Returns the DC Voltage value of the output in volts.
MEAS:VAC? Returns the AC Voltage value of the output in volts.
MEAS:I? Returns the Current RMS value of the output current in amps.
MEAS:IDC? Returns the DC Current value of the output current in amps.
MEAS:IAC? Returns the AC Current value of the output current in amps.
MEAS:FREQ? Returns the output frequency measurement in Hz.
MEAS:VPK? Returns the peak voltage of the output measurement in volts.
MEAS:IPK? Returns the peak current measurement at the output in amps.
MEAS:CF? Returns the crest factor measurement of the output voltage
MEAS:IS? Returns the inrush current of the output current in amps.
MEAS:POWER? Returns the true power output measurement in watts.
MEAS:VAR? Returns the reactive power output measurement in VAR.
MEAS:VA? Returns the apparent power output measurement in volt-amps.
MEAS:PF? Returns the Power Factor of the output power.
MEAS:ALL? Returns all 14 measurements, Output State and Alarm code as a comma
separated data string.
The order in which measurement values are returned is as follows.
Index - Measurement Index – Measurement Index – Meas. / State
0 – Vrms 6 – Freq 12 – VAR
1 – Vac 7 – Vpk 13 – VA
2 – Vdc 8 – Ipk 14 – PF
3 – Irms 9 – CF 15 – OUTPUT STATE
4 – Iac 10 – Is 16 – ALARM CODE
5 – Idc 11 – PWR
Table 7-2: Measurement Commands
