CPS100 SERIES OPERATION MANUAL
SECTION 4: TECHNICAL SPECIFICATIONS
Entire Contents Copyright  2018 by Adaptive Power Systems, Inc. (APS) • All Rights Reserved • No reproduction without written authorization from APS.
APS CPS100 Series Power Source Operation Manual Page 31 of 231
System Parameters, Protections & Control Interfaces
SYSTEM PARAMETERS
Model
CPS106~CPS115
CPS120~CPS150
Display
4.3” Color Touch LDC
640 x 480 pixels
5.6” Color Touch LCD
640 x 480 pixels
Data Entry Modes
Soft Keys, Numeric Keypad, Shuttle, USB stick
Output Protection
OCP, OVP, OTP, RCP
AC Input Protection
PRI-UVP, PRI_OTP, PRI_OCP
Control Interfaces (std).
USB, RS232,
RS485 (A/B)
USB, RS232
RS485 (A/B), LAN
Optional Interface
LAN + GPIB
GPIB
AC Input
INPUT VOLTAGE & CURRENT SPECIFICATIONS
Model
CPS106
CPS110
CPS115
CPS120
CPS130
CPS140
CPS150
AC Input Voltage
90 - 265 Vac
100 - 265 Vac
190 - 265 Vac, Single Phase (L, N, G)
Phases
1 Phase, 2W+G
1 Phase, 2W+G / 2 Phase L-L + G
Line Frequency
47 - 63 Hz
47 - 63 Hz
Max. AC Current
10 A
15 A
19 A
14 A
20 A
25 A
30 A
Input Power Factor @
F.L.
> 0.91 > 0.95 > 0.98 > 0.98 > 0.99 > 0.99 > 0.99
Efficiency @ Full Load
80 %
84 %
86 %
86 %
85 %
86 %
86 %
Note: AC input current values shown in the table above apply under full power output
conditions. The actual AC input current will be a function of the output power and is
shown at either 110Vac and 220Vac output voltage and 115Vac and 230Vac input
voltage by model.
