PARALLEL / SERIES / 3-PHASE Screen
This screen allows configuration of multi-unit systems in one for three available
configurations:
• Parallel Mode Two or more units can be paralleled to provide higher power and
current output. The maximum number of units supported in
parallel mode is 4.
• Series Mode Two units can be used in series to obtain a higher output voltage.
The maximum number of units supported in series mode is 2.
• 3-Phase Mode Three units can be used in a three phase Wye or Delta configuration
to obtain a three phase power source. The maximum number of
units supported in 3-Phase mode is 3.
For details on multi-unit configuration operation and use, refer to section 8, “Master Slave
Operation” on page 174 of this manual.
