CPS100 SERIES OPERATION MANUAL
SECTION 4: TECHNICAL SPECIFICATIONS
Entire Contents Copyright  2018 by Adaptive Power Systems, Inc. (APS) • All Rights Reserved • No reproduction without written authorization from APS.
APS CPS100 Series Power Source Operation Manual Page 29 of 231
OUTPUT SPECIFICATIONS
External Voltage Sense
Remote sense, Max Vdrop 5.0V
Line Regulation
± 0.1 V
Harmonic Distortion (THD)(Full
Resistive Load)
15-70Hz: < 0.3% @ 80-140Vac in Low Range, @ 160-280Vac in High
Range
70.1-500Hz: < 1% @ 80-140Vac in Low Range, @ 160-280Vac in High
Range
501-1000Hz: < 1% @ 100-140Vac in Low Range, @ 160-280Vac in
High Range
1001-1200Hz: < 2% @ 100-140Vac in Low Range, @ 160-280Vac in
High Range
Ripple & Noise (rms)
L: < 700 mVrms @ 20Hz-1MHz BW
H: < 1100 mVrms @ 20Hz-1MHz BW
Ripple & Noise (peak)
< 4000mVpp @ 20Hz-1MHz BW
Voltage Rise / Fall time
< 180 usec
Over Current
Fold-back
Resolution
0.01 A
Accuracy
± ( 0.5% setting + 1.0% F.S. )
Response
< 1400 msec
Metering
CURRENT & POWER MEASUREMENTS
Model
CPS106
CPS110
CPS115
CPS120
CPS130
CPS140
CPS150
Current
RMS
(Arms)
High Range
0.1-5.46
0.15-9.2
0.15-13.8
0.15-20.0
0.3-27.6
0.3-32
0.3-46
Med. Range
-
-
-
-
0.2-20A
0.2-20
0.2-20
Low Range
0.1-2.8
0.1-4.6
0.1-6.9
0.1-5
0.1-5
0.1-5
0.1-5
mA Range
-
-
-
0.02-1.5
0.02-1.5
0.02-1.5
0.02-1.5
Resolution
0.01 A
Accuracy
H/M: ± ( 0.4% setting + 1.0%
F.S. )
L/mA: ± ( 0.4% setting + 1.0%
F.S. )
H/M: ± ( 0.4% setting
+ 1.5% F.S. )
L/mA: ± ( 0.4%
setting + 1.2% F.S. )
H/M: ± ( 0.4%
setting + 1.0% F.S. )
L/mA: ± ( 0.4%
setting + 1.5% F.S. )
Peak Curr.
(A)
Range
0 - 32.4 A 0 - 81.5 A 0 - 81.5 A 0 - 81.5 A
0 - 168.6
A
0.05 -
163 A
0.05 -
188 A
Resolution
0.01 A
