Synthesis Commands
The Synthesis-commands allow creation of harmonic waveforms.
Command Description
SYNTHESIS:COMPOSE:_<nr2> Sets the data entry mode for harmonic amplitude programming
to either absolute value (0) or percent of fundamental (1).
Returns OK or FALSE.
SYNTHESIS:DEGREE:_<nr2> Sets the start phase angle of the waveform in degrees. Range is
0.0 ~ 359.0. Returns OK or FALSE.
SYNTHESIS:F:_<nr2> Sets frequency to either 50 Hz (0) or 60 Hz (1). Returns OK or
FALSE. <nr2> = < 0 | 1 >
Returns OK or FALSE
SYNTHESIS:PHASE:_<nr2>,<nr3>
Sets the phase angle for each order harmonic.
<nr2> 2 ~ 40
<nr3> 0.0 ~ 359.9
Returns OK or FALSE
SYNTHESIS:TRIGGER Start output of the synthesized waveform. Returns OK.
SYNTHESIS:STOP Stops running of the synthesized waveform. Returns OK.
SYNTHESIS:V:_<nr2>,<nr3>
Sets the amplitude for each order harmonic.
<nr2> 2 ~ 40
<nr3> See table for value ranges:
Order
2 ~ 10
11 ~ 20
21 ~ 30
31 ~ 40
Value (V)
0.0 ~ 150.0
0.0 ~ 120.0
0.0 ~ 80.0
0.0 ~ 45.0
Percent (%)
(0.0 ~ 100.0
% )* Vac
(0.0 ~ 50.0
% )* Vac
(0.0 ~ 30.0
% )* Vac
(0.0 ~ 15.0
% )* Vac
Where Vac = Fundamental Voltage. Amplitude of fundamental will be
fundamental voltage * setting %.
Returns OK or FALSE
SYNTHESIS:VAC:_<nr2> Sets the fundamental (H1) AC voltage in volts. Range is 0.0 ~
150.0 on 150V range, 0.0 ~ 300.0 on 300V range. Returns OK or
FALSE.
SYNTHESIS::VDC:_<nr2> Sets the fundamental (H1) DC voltage in volts. Range is -212.1 ~
212.1 on 150V range, -424.2 ~ 424.2 on 300V range. Returns OK
or FALSE.
SYNTHESIS:PHASE:ALL:_<nr2>
Sets the phase angle for all harmonics.
<nr2> 0.0 ~ 359.9
Returns OK or FALSE
SYNTHESIS:V:ALL_<nr2>,<nr3>
Sets the amplitude for all harmonics.
<nr2> See table for value ranges:
Order
2 ~ 10
11 ~ 20
21 ~ 30
31 ~ 40
Value (V)
0.0 ~ 150.0
0.0 ~ 120.0
0.0 ~ 80.0
0.0 ~ 45.0
Percent (%)
(0.0 ~ 100.0
% )* Vac
(0.0 ~ 50.0
% )* Vac
(0.0 ~ 30.0
% )* Vac
(0.0 ~ 15.0
% )* Vac
Where Vac = Fundamental Voltage. Amplitude of fundamental will be
fundamental voltage * setting %.
Returns OK or FALSE
