CPS100 SERIES OPERATION MANUAL
SECTION 4:
Technical Specifications
Entire Contents Copyright  2018 by Adaptive Power Systems, Inc. (APS) • All Rights Reserved • No reproduction without written authorization from APS.
APS CPS100 Series Power Source Operation Manual Page 28 of 231
4 Technical Specifications
Technical specifications shown here apply at an ambient temperature of 25° C ± 5° and after a 30
min warm-up time.
Output
OUTPUT POWER & CURRENT SPECIFICATIONS
Model
CPS106
CPS110
CPS115
CPS120
CPS130
CPS140
CPS150
Power Rating (VA/W)
600
1000
1500
2000
3000
4000
5000
AC
Current
(Adc)
150V
Range
5.6 9.2 13.8 16.0 27.6 32.0 46.0
300V
Range
2.8 4.6 6.9 8.0 13.8 16.0 23.0
Crest Factor
5.8 to 1
6 to 1
5 to 1
4 to 1
DC
Current
(Adc)
212V
Range
3.96 6.5 9.76 11.3 19.6 22.6 32.6
424V
Range
1.89 3.3 4.88 5.65 9.8 11.3 16.3
OUTPUT SPECIFICATIONS
Model
CPS106 ~ CPS115
CPS120 ~ CPS150
Voltage Ranges
AC Low / High
0 - 150 Vac / 0 - 300 Vac
DC Low / High
0 - 212 Vdc / 0 - 424 Vdc
Resolution
0.1 V
Accuracy
± ( 0.3% setting + 0.3% F.S. )
Waveforms
Sine, Square, Clipped Sine, Fixed (30), User (6)
Frequency
Range
S Versions: 15 - 1000 Hz,
E Versions: 15 - 1200 Hz
Resolution
0.1 Hz 15.0 - 99.9 Hz / 1 Hz 100 Hz - 1000 Hz / 5Hz 1001 Hz - 1200 Hz
Accuracy
± 0.1% of setting
± 0.03% of setting
Start/Stop Phase
Range
0 - 359.9°
Resolution
± 1° @ 45 - 65 Hz
Accuracy
±1%, 45- 65 Hz
Load Regulation
± 0.1% F.S. RL, DC, 15-100 Hz
± 0.5% F.S. RL, 100.1-1200 Hz
