CPS100 SERIES OPERATION MANUAL
SECTION 5:
Unpacking and Installation
Entire Contents Copyright  2018 by Adaptive Power Systems, Inc. (APS) • All Rights Reserved • No reproduction without written authorization from APS.
APS CPS100 Series Power Source Operation Manual Page 50 of 231
5.8.3 Rear Panel Models CPS130, CPS140, CPS150
The AC or DC output terminal is located on the left hand side when facing the back panel of
the power source.
Figure 5-6: Output Terminal Locations - 4U Models
