Harmonics Measurement Commands
Harmonics Measurement commands are all query which return a measurement result.
Note: These commands apply to Enhanced model versions of the CPS Series only.
Note: These measurement commands apply to an individual CPS100 series power source.
For Master/Slave configuration measurement commands, refer also to Section
7.2.2, “Master / Slave Measurement Commands” on page 171.
Command Description
HARMONICS:MEASURE:RUN Starts the harmonics measurement. Returns OK or
FALSE.
HARMONICS:MEASURE:STOP Stops the harmonics measurement. Returns OK or
FALSE.
HARMONICS:MEASURE:FREQ:_<NR2> Sets the fundamental frequency for the harmonics
measurement. Allowable values are:
0 50 Hz
1 60 Hz
Returns OK or FALSE.
HARMONICS:MEASURE:TIMES:_<NR2> Sets the measurement time for the harmonics
measurement. Allowable values are:
0 Single
1 Continuous
Returns OK or FALSE.
HARMONICS:MEASURE:SOURCE:_<NR2> Sets the measurement source for the harmonics
measurement. Allowable values are:
0 Voltage
1 Current
Returns OK or FALSE.
HARMONICS:MEASURE:ALL? Returns all 41 harmonic measurement values as a
comma separated data string.
Table 7-3: Measurement Commands
