4.11.5 GPIB Interface (Option)
GPIB Interface
Connector Type
24-pin Amphenol micro ribbon connector
Connector Location
Rear Panel
Address Range
1 ~ 30
Options for CPS106, CPS110, CPS115
Model
CPS106, CPS110, CPS115
Option –EXT: External I/O
DIGITAL I/O
TTL Inputs
Output ON/OFF, KEEP OFF, RESET, RECALL SETUP 1-7 (3 bits)
Relay Contacts
3 sets, PASS, FAIL (contact closure)
Connector Type
20 Position dual row compression
ANALOG
Voltage Input
Modes: SYNC or ANALOG, RMS. SET
Connector Type
BNC
Option -MSB: Master/Slave Bus
System Interface Bus
Modes Parallel
4 units max. for higher power
Series
2 units max. for 600V output
Three Phase
3 units in Delta or Wye Configuration
Note: Options –EXT and -MSB are mutually exclusive, i.e. only one can be installed at any time.
Options for CPS120, CPS130, CPS140, CPS150
Model
CPS120, CPS130, CPS140, CPS150
Option –AUX: Auxiliary I/O and Master/Slave Bus
Same as for CPS106 ~ CPS115 and adds:
Relay Contacts
Adds 1 set
System Interface Bus
Modes Parallel
4 units max. for higher power
Series
2 units max. for 600V output
Three Phase
3 units in Delta or Wye Configuration
