APS CPS100 Series - Programmable Functions; Test Functions; Dimensions & Weight

CPS100 SERIES OPERATION MANUAL
SECTION 4: TECHNICAL SPECIFICATIONS
Entire Contents Copyright  2018 by Adaptive Power Systems, Inc. (APS) • All Rights Reserved • No reproduction without written authorization from APS.
APS CPS100 Series Power Source Operation Manual Page 32 of 231
Programmable Functions
PROGRAMMABLE FUNCTIONS
Transients
(Available from
15-70Hz)
Modes
List, Pulse, Step
Parameters
AC Voltage, Frequency, DC Voltage, Current, Start Phase, Stop Phase
Timing
Transition Time: 0.0 - 66.5 ms @ 15Hz
Resolution: 0.1 sec
Transient Count: 0 - 9999
Test Mode
Pass/Fail based on Measurements
Test Functions
TEST MODE PARAMETERS
Memories
1 through 50
Steps / Memory
1 through 9
Memory Cycling
0 - 9999, 0 = Cont., 1 = OFF
Test Limits
Frequency, Current Hi/Lo, Power Hi/Lo, App. Power Hi/Lo, PF Hi/Lo
Ramp Up or Down
0.0 - 999.9
Delay
0.5 - 999.9
Dwell
0.5 - 999.9
Step Cycles
0 - 9999, 0 = Cont., 1 = OFF
Connect
ON, OFF
Surge / Drop Voltage
ON: Start 0-20ms, Duration 0-20ms
OFF: Start 0-99ms, Duration 0-99ms
Dimensions & Weight
MECHANICAL & ENVIRONMENTAL SPECIFICATIONS
Model
CPS106
CPS110
CPS115
CPS120
CPS130
CPS140
CPS150
Dimensions (W x
H x D)
432 x 87 x 520 mm
432 x 133 x 520 mm
432 x 177 x 520 mm
17” x 3.425” x 20.5”
17” x 5.24” x 20.5”
17” x 7” x 20.5”
Shipping Size (W
x H x D)
744 x 241 x 594 mm
597 x 276 x 694 mm
597 x 321 x 694 mm
29.3” x 9.5” x 23.4”
23.5”x10.9”x27.3”
23.5” x 12.6” x 27.3”
Rack Mount
Width w/Handles & Rack Ear Kit = 483 mm / 19”. Shelf or L-Bracket Support Required
Weight Net
15.9 Kg/35 lbs
21Kg / 47.2 lbs
29 Kg / 63.9 lbs
Shipping
19 Kg/42lbs
24.4 Kg / 53.8
32 Kg / 70.5 lbs
Dimension drawings for each size model shown on next few pages.
