Output Terminals
The location and size of the AC or DC output terminals is model dependent. The rear panels
for each model are shown here for reference.
Note: Always refer to Section 2.3 “Safety Information” and Section 2.4 “Safety Notices”
before making any load connections.
5.8.1 Rear Panel Models CPS106, CPS110, CPS115
The AC or DC output terminal is located on the left hand side when facing the back panel of
the power source.
Figure 5-4: Output Terminal Locations - 2U Models
5.8.2 Rear Panel Model CPS120
The AC or DC output terminal is located on the left hand side when facing the back panel of
the power source.
Figure 5-5: Output Terminal Locations - 3U Models
