CPS100 SERIES OPERATION MANUAL
SECTION 4: TECHNICAL SPECIFICATIONS
Entire Contents Copyright  2018 by Adaptive Power Systems, Inc. (APS) • All Rights Reserved • No reproduction without written authorization from APS.
APS CPS100 Series Power Source Operation Manual Page 30 of 231
CURRENT & POWER MEASUREMENTS
Accuracy
H/M: ± ( 0.4% setting + 1.0%
F.S. )
L/mA: ± ( 0.4% setting + 1.0%
F.S. )
H/M: ± ( 0.4% setting
+ 0.6% F.S. )
L/mA: ± ( 0.4%
setting + 1.0% F.S. )
Power
(Watts)
Range
0-612
0-1020
0-1530
0-2040
0-3060
0-4080
0-5100
Resolution
0.1
Accuracy
± ( 0.4% setting + 1.0% F.S. ) @ PF > 0.2 and Voltage > 5.0 V
App. Power
(VA)
Range
0-612
0-1020
0-1530
0-2040
0-3060
0-4080
0-5100
Resolution
0.1
Accuracy
Calculated, Vrms * Irms
Reactive
Power
(VAR)
Range
0-612
0-1020
0-1530
0-2040
0-3060
0-4080
0-5100
Resolution
0.1
Accuracy
Calculated, √(VA
2
- W
2
)
VOLTAGE, FREQUENCY & POWER FACTOR MEASUREMENTS
Voltage
AC Range
0 - 300 Vac
DC Range
0 - 424 Vdc
Resolution
0.1 V
Accuracy
± ( 0.2% setting + 0.2% F.S. )
Frequency
Range
S Version: 15 - 1000 Hz,
E Version: 15 - 1200 Hz
Resolution
0.1 Hz 15.0 - 99.9 Hz
1 Hz 100 Hz - 1000 Hz
5 Hz 1001 Hz - 1200 Hz
Accuracy
± 0.1% of setting
Power
Factor
Range
0.00 - 1.00
Resolution
0.01
Accuracy
Calculated W/VA
