CPS100 SERIES OPERATION MANUAL
SECTION 7:
Remote Control Programming
Entire Contents Copyright  2018 by Adaptive Power Systems, Inc. (APS) • All Rights Reserved • No reproduction without written authorization from APS.
APS CPS100 Series Power Source Operation Manual Page 157 of 231
Command Description
OUTPUT:WAVEFORMA? Queries the parameters of waveform A. Possible return
values are:
0 SINE
1 SQUA
2,60 CSINE, AMP = 60%
3,4 FIXED, NO. 4
4,3 USER, NO. 3
OUTPUT:WAVEFORMB:_<nr2>,<nr3> Sets the parameters of waveform B. Return signal is OK or
FALSE.
<nr2> 0 SINE
1 SIQUA
2 CSINE <nr3> 0 ~ 100
3 FIXED 0 ~ 29
4 USER 0 ~ 5
OUTPUT:WAVEFORMB? Queries the parameters of waveform B. Possible return
values are:
0 SINE
1 SQUA
2,60 CSINE, AMP = 60%
3,4 FIXED, NO. 4
4,3 USER, NO. 3
OUTPUT:ONDEGREE:_<nr2> Sets the start phase angle in degrees. Range is 0.0 ~ 359.9.
Returns OK or FALSE.
OUTPUT:ONDEGREE? Queries the start phase angle
OUTPUT:OFFDEGREE:_<nr2> Sets the end phase angle in degrees. Range is 0.0 ~ 359.9.
A 360 setting means DISABLE. Return signal is OK or
FALSE.
OUTPUT:OFFDEGREE? Queries the end phase angle
OUTPUT:SLEW:VOLT:AC:_<nr2> Sets the slew rate of the AC output voltage in V/ms. Range
is 0.001 ~ 1200.000. Returns OK or FALSE.
OUTPUT:SLEW:VOLT:AC? Queries the AC output voltage slew rate setting in V/ms.
OUTPUT:SLEW:VOLT:DC:_<nr2> Sets the slew rate of the DC output voltage in V/ms. Range
is 0.001 ~ 1000.000or 0 (disabled). Returns OK or FALSE.
OUTPUT:SLEW:VOLT:DC? Queries the DC output voltage slew rate setting in V/ms.
OUTPUT:SLEW:FREQ:_<nr2> Sets the slew rate of the output frequency in Hz/ms.
Range is 0.001 ~ 1600.000. Returns OK or FALSE.
OUTPUT:SLEW:FREQ? Queries the output frequency slew rate setting in Hz/ms.
OUTPUT:IMPED:FLAG:ON
OUTPUT:IMPED:FLAG:OFF
Enables (ON) or disables (OFF) the output impedance
function. Returns OK or FALSE.
OUTPUT:IMPED:FLAG? Queries the output impedance function status. Returns
ON of OFF.
